Mobile grandstands
Mobile grandstands Built from tested platforms – as big as your audience
Every mobile grandstand is built from BÜTEC Standard or Compact platforms: 750 kg/m² distributed load, TÜV GS-tested, only approx. 95 mm high in storage. Standing or seated, indoors or outdoors – you decide the shape, the height and the seats.
- Load750 kg/m², 1.7× safety factor
- Typestanding or seated
- Useindoors and outdoors
- Storage heightapprox. 95 mm per platform
Benefits
One platform system, any grandstand shape
Shaped to your room
Straight, angled, curved, with an upper tier or with space underneath: because the grandstand is made of single platforms, it follows your floor plan.
Any seat fits
From theatre chairs, stacking chairs and benches to light plastic seat shells. Without seats, the grandstand becomes a standing terrace.
Accessories without drilling
The compact corner has standard threads at every corner. Seats, benches and railings are fixed firmly with standard screws.
Indoors and outdoors
In the sports hall, beside the football pitch, along the running track or at an outdoor event. For outdoor use there are hardwood benches and UV-protected seat shells.
Matched to the room
Aluminium frames and decks are finished in colours to suit the room, with wood or fabric cladding and step lighting.
Stored flat
Taken down, each platform with its storage caps is only approx. 95 mm high – the grandstand fits stacked into the equipment room.
How your grandstand is built
The same platforms as your stage – only stepped
A mobile BÜTEC grandstand is a system of tested single parts. That makes it adaptable, extendable and compatible with the whole platform accessory range.
Platforms
Aluminium frames from 50 × 50 cm to 200 × 100 cm, 90 mm frame height, decks from beech and film-faced plywood to parquet or carpet.
Heights
Up to 1.2 m build height without diagonal bracing, above that with diagonal braces. For the classic theatre rake there are the Master and Giga frame systems with a 16 2/3 cm frame height.
Accessories
Railings, stairs, claddings, step lights and ramps come from the BÜTEC platform accessory range – made for exactly these platforms.
Technical data
Standard and Compact platforms at a glance
Platform
- Dimensions
- 50 × 50 cm to 200 × 100 cm
- Frame
- aluminium, 90 mm high, natural or anodised, groove on the inside
- Leg sockets
- four die-cast zinc corners with pressure plates that protect the material
- Decks
- 22 mm beech, film-faced plywood, parquet, laminate, grating, linoleum, carpet and more
- Weight
- approx. 15 kg without deck (2 × 1 m)
- Storage height
- approx. 95 mm including storage caps
Load and build
- Working load
- 750 kg/m² static distributed load, TÜV GS-tested, safety factor 1.7
- Point loads
- calculated separately
- Build heights
- up to 1.2 m without, above that only with diagonal bracing
- Theatre rake
- with the Master or Giga frame system, 16 2/3 cm frame height
- Documents
- tests to DIN EN 13200, DIN 4112, DIN 1055; TÜV inspection books for grandstands indoors and outdoors
References
In use Sports halls, studios, trade fairs and sports grounds
Accessories
Matching accessories Railings, stairs and more
Downloads Brochures on grandstands and platforms
For planners
Questions
Set-up, safety, height, seats Questions about mobile grandstands
How fast is a mobile grandstand set up?
That depends on size, height and shape – we plan the set-up and the crew with you. If the grandstand is set up and taken down several times a week, look at the Push'n Pull: there, one person pulls out a block with 10 rows in five minutes.
Is a grandstand made of platforms safe enough for an audience?
The Standard and Compact platforms carry 750 kg/m² and are TÜV GS-tested with a 1.7 safety factor. There are TÜV inspection books for grandstands indoors and outdoors. Which documents your event needs depends on your local building and venue regulations – we agree the structural calculations and documents with you.
How high can the grandstand be?
Up to 1.2 m build height without diagonal bracing. We build higher grandstands with diagonal braces, and from 160 cm also with infill panels.
Which seats are possible?
Seat shells, stacking chairs, benches or theatre chairs. Without seats, you use the grandstand as a standing terrace. See all seating options.
How do we get a quote?
Send us a sketch or drawing with dimensions and the number of seats you need. You receive a quote for your grandstand.
A sketch is enough We plan your mobile grandstand
Send us the dimensions, the number of seats and where it will stand – indoors or outdoors. We propose the shape, height, seats and railings and prepare a quote.
