Mobile telescopic grandstand
Push'n Pull One person pulls out 40 seats in five minutes
Lift the lowest platform, pull it out – all rows behind it follow and lock into place. No motor, no power connection, no single platforms to clamp together. After the event, the block pushes back together to 1.25 × 2 m. Telescopic seating, also called retractable seating, that one person operates.
- Set-up1 person · 5 min per block
- Blockup to 10 rows, 2 m high
- Seats40 per block
- Powernot required
- Storage1.25 × 2 m per block
Benefits
Fewer hands, fewer hours What the Push'n Pull takes off your hall team
5 minutes per block
A block with 10 rows, up to 2 m high and 2 m wide, is pulled out or pushed back in five minutes. By one person.
No power, no motor
The grandstand is pulled out by hand. You need no power connection and no drive, and you have no energy costs. The system needs little maintenance.
1.25 × 2 m in storage
Retracted, one block stands on 1.25 × 2 m. Pulled out with 10 rows, that is 40 seats or 19.5 m² of grandstand area.
Anywhere in the room, extendable block by block
Each block is moved with a pallet truck or on built-in transport castors that retract pneumatically. More blocks can be added at any time.
Only as many rows as you need
For each event you decide: pull out all rows or only some of them. Rise, depth and surface are configured per block.
Guided in parallel, with structural calculations
A shaft with rack guides underneath keeps the rows parallel, so the block cannot twist while you pull. Delivered with structural calculations to Eurocode 9 and DIN.
How it works
From block to grandstand in four steps, by one person
No single platforms to place, no plug-in legs to lock, nothing to clamp. The tools come with the grandstand: a pull-out bar and a locking key.
Position the block
Move the block to where you need it – with a pallet truck or on the optional transport castors that retract pneumatically.
Lift the lowest platform
Place the pull-out bar under the lowest platform and lift it.
Pull it out
Pull the lowest platform forward. All other rows follow automatically and lock in the correct position.
Fit the railing, lock the blocks
The aluminium railing is plugged in or screwed on. Blocks standing side by side are locked from above with the Quick-Lock key – no connecting clamps.
Video
Watch it One block, one person, five minutes
Where it is used
One grandstand, many rooms Where the Push'n Pull is in use
Sports and multi-purpose halls
School sport in the morning, an audience in the afternoon: the blocks stand retracted against the wall and are pulled out before the doors open.
Presentation halls
As spectator seating for demonstrations and company events – afterwards the floor is free again for exhibits.
Theatres and studios
As a flexible theatre stage, stepped stage, show staircase or choir loft. Custom versions adapt the grandstand to your room.
Halls with chairs
With Pro Comfort grandstand chairs, the Push'n Pull becomes raised seating rows for concerts, talks and meetings.
Technical data
Push'n Pull at a glance
Dimensions
- Block size (standard base block)
- 1.25 × 2 m, other sizes on request
- Pull-out depth
- 0.95 × 2 m, other depths on request
- Rise per row
- 16.66 to 40 cm
- Rows
- up to 10, e.g. 2 m high at 2 m wide
- Storage space
- 1.25 × 2 m per block (with 10 rows: 40 seats or 19.5 m² of grandstand area)
Load and documents
- Load capacity
- 500 kg/m², other load capacities on request
- Structural calculations
- to Eurocode 9 and DIN (DIN EN 1991, 1993, 1995, 1999, DIN 68705)
- Platform system
- BÜTEC Compact, Standard or Master
Operation
- Set-up
- 1 person, 5 minutes per block (out and in)
- Pull-out
- by hand with the pull-out bar; all rows follow automatically
- Guidance
- shaft with rack guides for smooth parallel movement
- Connecting blocks
- BÜTEC Quick-Lock, locked from above
- Moving
- pallet truck or built-in transport castors that retract pneumatically
- Power supply
- none
Equipment
- Surfaces
- beech plywood, film-faced plywood, STAB Light board, parquet, linoleum, laminate, needle felt / carpet, others on request
- Railings
- aluminium, plug-in or screwed: special round-tube plug-in railing, grandstand railing, grandstand railing II, hoop railing with safety mesh
- Step lights
- in the frame profile, behind the frame profile or in the deck
- Seating
- Pro Comfort grandstand chair A, B or C
- Finish
- e.g. black powder coating, full or fabric cladding, LED
References
In use Sports halls, assembly halls, presentation spaces
Accessories
Matching accessories Railings and step lighting
Railings8
Bail railing steel 110 cm
Height: 110 cm
Grandstand railing aluminium 110 cm
Height: 110 cm
Grandstand railing II aluminium 110 cm
Weight: approx. 8.0 kg/m
Railings
Material: steel or aluminium
Custom railings
Material: steel or aluminium
Legs & feet1
Surfaces & skirting2
Deck boards
Indoors: beech, parquet, laminate, linoleum
Claddings
Materials: wood, fabric, acrylic glass, metal
Transport1
Lighting & mounting1
Step lighting
Technology: LED
Floors1
Floor protection Protect
Tiles: 2 × 1 m, no adhesive
floor protection also works as a carpet layer on grandstands
Seating5
Seating options
Types: shells, chairs, benches, theatre chairs
Seat shells
Frankfurt: 44 cm wide, 1.4 kg
Benches
Wood: multiplex beech, hardwood
Theatre chairs
Type: folding or fixed
Systems3
Comparison
Comparable systems The alternatives side by side
Same job, different focus – the key specs next to each other.
Push'n Pull mobile telescopic grandstand
This page- Set-up
- 1 person · 5 min per block
- Seats
- 40 per block
- Set-up
- –
- Seats
- –
- Set-up
- 1 person · 10 min
- Seats
- 124 (114 with 2 stairways)
- Set-up
- –
- Seats
- –
Downloads Brochure and grandstand chair
For planners
Tender text / CADOn request – we send you tender texts and CAD data for your project.Request
Questions
Motor, load, rows, seats What venue managers ask about the Push'n Pull
Why not a motorised telescopic grandstand?
Because the Push'n Pull reaches the same goal without a motor: one person pulls out a block in five minutes. You need no power connection, you have no energy costs, and every block can be placed freely in the room. That makes it an alternative to motorised telescopic seating, in price and in function.
How much load does the Push'n Pull carry?
500 kg/m² as standard. Other load capacities are possible on request. The grandstand is delivered with structural calculations to Eurocode 9 and DIN.
Can several blocks form one continuous grandstand?
Yes. You pull out the blocks side by side and lock them from above with the Quick-Lock key that comes with them. No connecting clamps between the rows are needed.
Do we always have to pull out all rows?
No. Depending on the event, you use all rows or only some of them.
How do we move the blocks through the hall?
With a pallet truck, or on a built-in set of transport castors that retract pneumatically. You can order the castors as an option.
Which seats fit?
The Pro Comfort grandstand chairs A, B and C are made for the Push'n Pull – without link, with row link or with armrests. We can also plan benches or other seats.
Is the Push'n Pull available in custom sizes?
Yes. Block size, pull-out depth and surface can be adapted on request, up to a custom build for your room.
How many blocks does your hall need? We work it out with you
Tell us the hall dimensions, the number of seats and the storage space you have. You receive a proposal for the number of blocks, the rise and the equipment – and a quote.
